PREORDER - Pinner OPI - Pinball HAT (ORANGE Pi5 MAX - Not Included BUT IS REQUIRED!)

⚠️ READ BEFORE PURCHASING — IMPORTANT COMPATIBILITY NOTICE ⚠️

This is currently a PRE-ORDER! PRE-ORDERS will ONLY be open for 2 WEEKS! After the PRE-ORDER period closes it can take up to ONE MONTH to receive your kit! Depending on delivery times, availability of components needed this could be slightly longer and will be treated on a first come first serve basis. We will keep everyone updated as much as we possibly can with weekly posts on our facebook page on updates once pre-orders close.

This product is ONLY for use in Arcade1Up™ Pinball Machines. It has absolutely NO FUNCTION outside of that context.

⚠️ This is not an official product, it is not supported by affiliated with or created by Arcade1up or Zen Studios in ANY way. ⚠️

An Orange PI5 Max is REQUIRED and is NOT included!
🔴 This HAT cannot and will not function without an Orange Pi 5 MAX single board computer. If you do not have an Orange Pi 5 MAX, PURCHASE ONE FROM AMAZON via the "Required Parts" linked below!

🔴 This only comes with tables for your stock Arcade1up pinball machine and is intended as a repair product. For additional tables you MUST purchase them from Zen Studios via their Zen Pinball application! We will NOT provide these to you.

🔴 If your cabinet has been modified with a Nintendo Switch, PC, or other such modification. You will need to re-install your stock control encoder and power distribution board, this will not function without them.

Before placing your order, please carefully review the full list of required components here:
👉 Required Parts

By making this purchase, you acknowledge that you fully understand what is required and that you accept all terms and conditions outlined in our Terms of Service (including the assumption of risk and limited warranty policies).

🛠️ Installation

- Installation is simple and there are written instructions included as well as videos provided for installation instruction. The process (Not including the LVDS converter) is relatively the same as installing a new stock PCB with the exception of the LVDS converter and power to the SBC no new wires or cords are required.

🛠️ Product Overview

The Pinner OPI is a custom-designed HAT for the Orange Pi 5 MAX, purpose-built to integrate with Arcade1Up™ Pinball Machines.

This acts as a full kit when paired with the required components to replace your stock PCB in your Arcade1Up™ pinball machine, with fully working software provided by Team Encoder. It enables advanced features such as:

Enhanced resolutions up to 1080p and 2K (4K requires additional cooling and is done at your own risk).

4x MSAA (Multisampling Anti-Aliasing)

Super-sampling support

Ability to load additional tables or software (⚠️That you legally purchase or obtain).

⚠️⚠️ If you do not want the Pinner software or modification installed and only wish to use this kit as a replacement for a failed stock PCB, please include a note in your order specifying which cabinet you have. We will configure the SD card so that the cabinet operates as it normally would—retaining original functionality with the added benefit of 1080p and 4x MSAA improvements.

🟢 This kit FULLY supports all stock functionality solenoids, DMD, plunger, and buttons with no new control encoder.

Standard Kit Includes:

🟢 Pinner OPI (our custom pinball HAT)

🟢 Preloaded SD card with our custom software (referred to as Pinner)

🔺 This does not include Zen Pinball tables outside of those intended to run on your Arcade1up Pinball machine, if you want Zen Pinball tables you MUST purchase them from Zen Studios via the Zen Pinball Android (PC, Switch, iPhone or other will not be compatible!) application.

🟢 3D-printed LVDS mount for securing your own LVDS converter board

🟢 Mounting hardware to secure your Orange Pi 5 MAX (not included) to the cabinet

🟢 Y-splitter cable to share power with your LVDS converter

🟢 DC power extension cable

🟢 Printed installation instructions

Basic (Non-Kit) Version Includes:

🟢 Pinner OPI (our HAT)

🟢 Preloaded SD card with Pinner software

🔺This does not include Zen Pinball tables outside of those intended to run on your Arcade1up Pinball machine, if you want Zen Pinball tables you MUST purchase them from Zen Studios via the Zen Pinball Android application.

🔺 This version is intended only for users who have already modified their Arcade1Up™ Pinball cabinet screen to accept HDMI input.

⚖️

Legal & Warranty Disclaimer

By purchasing any version of this product, you agree to the following:

All sales are final.

You assume all risk associated with the installation and use of this product.

We are not responsible for any damage to your cabinet, screen, SBC, or any other hardware or software caused by proper or improper installation or use.

This product comes with no warranty, express or implied, beyond what is outlined in our Terms of Service.

Support requests must be submitted via our website contact form, Discord, or Facebook. We aim to respond within 72 hours.

We reserve the right to permanently disable any software or device associated with this product in the event of fraud or chargebacks.

🔁

Final Reminder

🔺 Please ensure you have read and understood:

What you're purchasing

What is required to make it work

That this product has no use outside of an Arcade1Up™ Pinball cabinet

That an Orange Pi 5 MAX is REQUIRED for the HAT to function

If you're unsure, please contact us before purchasing.
